Techpaulin Cross Laminated Films
An Introduction To Techpaulin
Cross Laminated
Multi Layer
Multi Axis Oriented
It comprises of biaxial oriented layers of plastic film bonded to one another in the machine operating direction, transverse and angular axis all together in 16 directions bonded by a cold roll technique.
Techpaulin has exceptional puncture resistant & barrier property, cutting-edge manufacturing technology delivers a superior product that does not peel off, shred, crack or cause leak easily. Extremely light weight but stronger. High UV property delivers better crack & weather resistance.
It is odourless, non toxic, recyclable, food grade and can be used for protecting, covering food grade items as well.
TECHPAULIN – A SUPERIOR PRODUCT
| Conventional Tarpaulin |
| Made of woven polyethylene fabric laminated with poly film |
| Due to inherent product manufacturing process, product gets delaminated, disoriented very fast with loose shreds and ends |
| Lamination develops crack and tarpaulin shreds, poor weathering resistance |
| Inherent product structure makes it heavy |
| Stitching is done for side reinforcement, but has poor life as stitch wears off easily |
| Poor water resistance & poor barrier property |
| On exposure to sunlight conventional tarpaulin weakens rapidly developing cracks and shreds |
| Eyelets provided on reinforced sides weakens tarpaulin as it tears off easily |
| Surface does not allow excellent printing |
| Large variation in GSM / thickness |
| Other conventional Tarpaulin such as PVC Tarpaulin are heavy, not moisture resistant and difficult to handle |
| Develops bad odour when in contact with moisture. Toxic and non food grade |
| Post service waste generated is not eco-friendly |
| Techpaulin |
| Multilayer multi axis Oriented X cross laminated film |
| Superior technology enables film to have excellent lamination and weathering resistance |
| Excellent weathering resistance. Does not shred or crack easily. Its 5 times more durable |
| As the film has got exceptional strength, it is much lighter in weight |
| Side reinforcement are done by ultrasonic welding technology, excellent weld property |
| Excellent water barrier property |
| Good weathering resistance even on exposure to sunlight |
| Strong and rigid eyelets are provided on side edges, does not weakens Techpaulin |
| Surface allows good printing and marking branding possible |
| Excellent technology allows very fine control & tolerance of GSM / thickness |
| Techpaulin is light weight and easy to handle |
| Odourless and non-toxic |
| Post service life, product is 100% recyclable, environmentally sustainable and eco-friendly |
Unique features that give techpaulin the definitive edge
Strong
Tear / Puncture Resistant
100% Waterproof
Easy to Use
Durable
Weathering Resistant
Chemical Resistant
UV Resistant
An entire range of Agricultural and Industrial Applications
Finer Details that make a world of a difference
Techpaulin is reliable, matches high quality standards and finds application in an extensive range of agricultural and industrial applications.
Ultrasonic Welding
Unlike other material sheets, which are joined by stitching and stapling or any other conventional process, Techpaulin sheets are joined by a hi-tech process of ultrasonic welding.
- Faster than conventional process
- Clean and precise joints
- Further guarantee that there is no leakage
Eyelets
Techpaulin provides reinforced eyelets at the corners and along the sides to form a strong attachment points for hold / grip & tying it.
- Prevent tearing or streching
- Eyelets branded originality identified
- Easier usage
- Extremely durable
- Longer service life
Extensive Range
Techpaulin is available in all popular standard formats & sizes, ready to use carpet / sheet & roll form also available for customization.
GSM / Thickness
Reinforced multi layer structure films ranges from ultra thin to heavy grade. Film is available in 70, 90, 120, 150, 200, 250, 300, 350 GSM.
Sizes
Techpaulin offers a wide range of size and also long size which can be fabricated to a custom-made size as per customer’s need.
Colours
A diverse range of colours.
Quality And Standards
Techpaulin is made from the finest material and constructed with the highest quality of workmanship with very latest state-of-the-art processing equipments. It is manufactured for performance exceeding IS Standard 14611-2016 (Multi layered cross laminated film).
Technical Values for Multi Layered Cross Laminated Sheets
| Characteristics | Requirements | ||||
| XLN Extra Light | LN Light | MN Medium | HN Heavy | XHN Extra Heavy | |
| Total mass per unit area, Min, g/m2 | 35-60 GSM | 70-100 GSM | 120-150 GSM | 200-250 GSM | 300 GSM |
| Tensile strength | Kg/cm2 | Kg/cm2 | Kg/cm2 | Kg/cm2 | Kg/cm2 |
| 1. Longitudinal direction | 250 | 250 | 250 | 250 | 250 |
| 2. Transverse direction | 200 | 200 | 200 | 200 | 200 |
| After ageing at 70+/- 1° for 168h, Min, Kg/cm2 | 30% decrease from the original | ||||
| 1. Longitudinal direction | |||||
| 2. Transverse direction | |||||
| Elongation at break, Min | % | % | % | % | % |
| 1. Longitudinal direction | 300 | 400 | 400 | 400 | 400 |
| 2. Transverse direction | 250 | 300 | 300 | 300 | 300 |
| Tear strength, Min | g | g | g | g | g |
| 1. Longitudinal direction | 650 | 1200 | 2080 | 3200 | 4000 |
| 2. Transverse direction | 450 | 900 | 1600 | 2800 | 3500 |
| After ageing at 70+/- 1° for 168h, Min, Kg/cm2 | 30% decrease from the original | ||||
| 3. Longitudinal direction | |||||
| 4. Transverse direction | |||||
| Dart impact strength, Min | g 100 |
g 250 |
g 400 |
g 700 |
g 800 |
| Average tensile strength & elongation at break after exposing to UV radiation and weathering, Min (kgf) | 50% of the original strength | ||||
